求助Allegro 16.3转PADS9.4.1

录入:edatop.com    点击:
谁会allegro 16.3转pads9.4.1 点击转换时出现下面的结果不知道哪里设置不对求解

From版主 [rx_78gp02a]
安装pads9.3.1之后的版本,软件自带了dfl skill,把它集成到allegro中,转换出mgc文件夹并用pads 9.3.1自带的allegro to pads translator 把brd转换成pads的pcb文件,教程在pads的安装目录里面有.
-------------------------
楼上可以试试版主说的方法

Please wait...extracting and processing technology file
Starting Export techfile...
techfile completed successfully, use Viewlog to review the log file.
techfile completed successfully, use Viewlog to review the log file.
Converting techfile...
Executing command E:/S/AA_MGC/Worktechconv.bat
Error: Techfile conversion failed!
extracting Layer Stackup
extracting Design Rules
Deleting Existing Classes File
Deleting Existing Props File
Deleting Existing Board Items File
Exporting Electrical Constraints...
Loaded existing device file 'E:SAA_MGCWorkdevices.dml'
Finished loading SigNoise device libraries
deleting old device files
extracting device files
extracting Net Properties
extracting Board Areas
extracting padstacks
extracting padstack completed
extracting Placement
E- *Error* greaterp: can't handle (nil > 0)这是我按照教程步骤输出的Allegro Command结果PADS 9.4.1导入时会出错 File Import failed。PADS file not created

Error: Techfile conversion failed!
E- *Error* greaterp: can't handle (nil > 0)问题估计是在这两条 但是不知道怎么改

高手呢?帖子就要沉下去了

问题还未解决 Jimmy版主能帮忙解决吗 会的高手留下联系方式我提供文件

顶起,我也是同样的问题

顶起,我也是同样的问题

一直在为PADS和PROTEL之间的转换问题发愁 不能完全的转换 总会有那么点问题

最终没搞定 只好用AD作为中间过渡转了下

用AD过渡的时候,转换出来的文件用pads直接import有没有出现什么问题?

有的板子确实转不了,可能是有些不支持的字符在里面或者是过长的属性值。

請問一下如果是出現下面訊息的錯誤
要怎麼解呢??
ERROR: Techfile conversion failed!
WARNING: layer BOTTOM not found in layer table.Check the Allegro cross-section!
WARNING: layer POWER not found in layer table.Check the Allegro cross-section!
WARNING: layer GND not found in layer table.Check the Allegro cross-section!
WARNING:Board outline is non-closed or self-intersecting; using its bounding box as a board outline
WARNING:No route border found, bounding box used!
ERROR: no data issued for clearance DEFAULT
WARNING: layer TOP not found in layer table.Check the Allegro cross-section!
WARNING: layer SOLDERMASK_TOP not found in layer table.Check the Allegro cross-section!
WARNING: layer SOLDERMASK_BOTTOM not found in layer table.Check the Allegro cross-section!
WARNING: layer PASTEMASK_TOP not found in layer table.Check the Allegro cross-section!
WARNING: layer PASTEMASK_BOTTOM not found in layer table.Check the Allegro cross-section!
WARNING: layer FILMMASKTOP not found in layer table.Check the Allegro cross-section!
WARNING: layer FILMMASKBOTTOM not found in layer table.Check the Allegro cross-section!
ERROR: Unable to issue shapes for padstack SMD25X25_R - layer problems
ERROR: Unable to issue shapes for padstack SMD25X25_L - layer problems
ERROR: Unable to issue shapes for padstack 052X072V - layer problems
ERROR: Unable to issue shapes for padstack SMD35X32 - layer problems

顶起!

allegro要求严格,任何非法字符都报错
