curbes from ads and hfss in the same graph
录入：edatop.com 点击：
hello
How we can obtain a one graph with 2 courbes from ADS and HFSS?
Many thanks
The solution is to export curves from ADS and HFSS (TXT format) and then use import data in MATLAB and then plot it
How we can obtain a one graph with 2 courbes from ADS and HFSS?
Many thanks
The solution is to export curves from ADS and HFSS (TXT format) and then use import data in MATLAB and then plot it
A better solution..
Export Touchstone s-parameter file from HFSS and convert it to ADS data file in ADS by using Data File loader and put 2 curves on a single plot.
10x for your answer
I don't know wy ADS can't find my Touchstone exported by HFSS
Can u plz add some pictures how to import touchstone file with ads
thank you very muchhhh
