stripline step discontinuity in ADS
录入:edatop.com 点击:
Hi there
in the attached figure, Since the lines are aligned in an straight but have no common center how to model the step discontinuity in ADS circuit model?
in the attached figure, Since the lines are aligned in an straight but have no common center how to model the step discontinuity in ADS circuit model?
There are no circuit models to analyze this with good accuracy. You should use an EM simulator for this layout.
